XP-1A SF6
XP-1A is an SF6 Analyzer developed by using the principle of negative corona, which has high sensitivity and stability. At the heart of this product is an advanced microprocessor, and its signal processing function is very good for manipulating the circuit and sensor signals. The XP-1A is a stable and reliable product in any environment.
Features
• Microprocessor core with advanced digital signal processing
• Three-color display
• Seven levels of sensitivity up to 64x
• Real-time sensitivity calibration
• Battery level test function
• Mute function included
• 14'' (35.5cm) bendable stainless steel probe
• Cordless and portable, with two size C batteries
• Detection of all halogen gases
Classic application
Leak Test Object:
• XP-1A Qualitative Leak Detector can be widely used for leak detection of all power equipment filled with SF6 gas. Such as: SF6 Analyzer of GIS, GIB, GIT, GIL, GICT, GIPT and other equipment.
Technical specifications
Technical Spe: | XP-1A |
Meassurement principle | Negative corona principle |
Meassurement limits | 5ppm |
Sensor life | ~20h |
Warm-up time | ≤3min |
Response time | Instantaneous |
Reset time | 1 second |
Warm-up time | 2 second |
Meassurement method | Hand-held inhalation |
Battery | 3VDC；2 “C” battery |
Battery operating time | 30h for normal use |
Duty cycles | Continuous measurement, unlimited |
Display mode | 7-panel tri-color LED display |
Calibration certificate | Original calibration certificate |
Operating temperature | 0℃-52℃ |
Weight & Size | |
Size | 229*65*65（mm） |
Weight (with equipment) | 500g |
Bendable probe length | 355（mm） |
Outer carton protection level | IP20 |
